`web_hook`

web_hook nodes handle inbound POST calls from external systems.

This page describes inbound webhooks that start or continue backend campaign logic. To send submitted lead form data from ResultFly to an external system, see Lead Form Webhooks.

Summary

Placement: Entry only (webhook calls start the flow).
Context: Backend apps.
Visual: No.
Level: Intermediate (requires integration setup).
Purpose: Accept external events and route them into campaign logic.

Support secret headers, HMAC signatures, and IP allowlists to secure integrations.
Map JSON payloads into $state fields or pass-through attachments for downstream use.
Provide explicit success/error responses so partners know when the automation accepts an event.

Example: update user variables


POST /api/hooks/campaign/{campaignId} HTTP/1.1
Authorization: Bearer {{ token }}
Content-Type: application/json

{
  "event": "user.update",
  "userId": "usr_9834",
  "variables": {
    "bonus": 50,
    "xp_delta": {
      "op": "increment",
      "value": 120
    }
  }
}

userId identifies the player whose state will be updated.
bonus sets the absolute value for a declared user variable (for example state.user_global.bonus).
xp_delta shows how to express a relative change; in this example the user gains 120 XP by incrementing the existing value.

Example: send arbitrary user events


POST /api/hooks/campaign/{campaignId} HTTP/1.1
Authorization: Bearer {{ token }}
Content-Type: application/json

{
  "event": "user.events",
  "events": [
    {
      "userId": "123456",
      "amount": 1299,
      "transactionId": "tx_001"
    }
  ]
}

Example ResultFly response:


HTTP/1.1 200 OK
Content-Type: application/json
Signature: sha256=3cb32e…

{
  "status": "accepted",
  "node": "node-web-hook-demo",
  "traceId": "hook_01J8XCG9YNX6",
  "next": "node-branch-loyalty"
}
